DVBMonitor

Real-time monitoring of multiple Transport Streams

DVB Networks are getting more complex rapidly. Besides the growing amount of Services, also the varieties of components that must connect and interact in a specific way to be successful are getting beyond human perception.

All activities together are responsible for the behavior and quality of a DVB network. Thereby DVB networks evolve constantly with changes in services, parameters, devices and their firmware releases. It can be concluded that a DVB network owner constantly needs to be aware of the quality of his DVB network! The most reliable means to know how a DVB network performs is to continuously measure in real-time its behavior through comparison to a set of recommendations for various stream elements.

The key question which has to be answered is: What do you accept or not in your DVB network?

To ensure that all DVB signals meet the customer requirements, constant real-time compliancy checks are needed.

Features

Web based Application Multiple Transport Streams Multiple Configurable Compliancy Checks Multiple Templates Multiple Notifications Multiple Organizations Multiple Sites Multiple Users
Freeze detection Black detection Silence detection Input Lost detection PID Lost detection Service Lost detection Multiple walls Acknowledge mode Visual signalling Audio alerts SNMP traps Mail alerts DVBMonitor connectivity	MPEG-2 / AVC (H.264) / HEVC (H.265) video MPEG / AAC, Dolby® Digital+, Dolby® E, Dolby® AC-4 audio Web enabled Remote control Teletext DVB-subtitles Clocks Images Preferences Aspect ratio detection ETR-290 (Level 1, Level 2, Level 3, and 4*) measurements SCTE-35 monitoring/logging
PID structures Service structures SI/PSI/PSIP structures ETR-290 compliance Timing Descriptors Bitrate measurement Teletext Subtitling Thumb overview Video Quality GOP structures PTS-DTS Timing	Table overview Table Change monitor Descriptor overview Hex Viewer PCR Timing Logging Filtering EPG Audio measurement Loudness measurement
And many more!!

Input Support

File, HD/SD SDI, ASI, DVB-C, DVB-T/T2, DVB-S/S2, DVB-H, Unicast, Multicast, SRT and

Live OTT Streaming (RTSP/RTMP/RTP/HLS/Smooth Streaming/MPEG_DASH).
